Carbon Molecular Sieves (CMS) made of active carbon are a special adsorbents, and be used in nitrogen generators in PSA (Pressure Swing Adsorption) process.



SyGasTec provides high preformance CMS for all purity range up to 99.9999% nitrogen.



We are delivering CMS-240, CMS-260, CMS-300  and CMS-330:

Performance with 1000kg/h:

  Adsorption pressure  (bar) N2 purity (%) output (L/kg.h) Air ratio Recovery %
CMS-240 7 99 310 2.19 53.63
99.5 250 2.54 46.13
99.9 187 3.17 37.04
99.99 112 4.63 25.33
99.999 80 6.2 19
CMS-260 7 99 345 2.14 54.58
99.5 280 2.49 47.14
99.9 210 3.09 38.14
99.99 125 4.47 26.39
99.999 88 5.9 19.99
CMS-300 7 99 373 2.1 55.61
99.5 300 2.44 48.11
99.9 255 3.02 39.02
99.99 135 4.32 27.31
99.999 92 5.6 21
CMS-330 7 99 405 2.04 57.22
99.5 330 2.37 49.52
99.9 240 3.06 38.56
99.99 182 4.28 27.53
99.999 92 5.6 21
above data with adsorption time 2x40s, inlet air temperature and room temperature ≤20oC



packages: 20kg drums and 137kg drums

one 20# Container full loading: in 20 kg drums 11520kg

                                              in 137 kg drums 10960kg



Actual whole 20# Container full loaded Hamburg CNF:

CMS-240: 7.45 EURO/kg

CMS-260: 7.63 EURO/kg

CMS-300: 8.10 EURO/kg

CMS-330: 8.58 EURO/kg

(above issued Prices are based on the international ocean freight in July 2020, and the actual CNF price is subject to the real-time international ocean freight price and valid until December 31. 2020)





CMS 20kg drums pallet loaded





CMS 20kg drums pallets Container loaded





CMS 137kg drums pallet loaded





CMS 137kg drums pallets Container loaded



CMS and Zeolite MS mixed Container loaded
